ANCTL-MP40G1
Multimedia Player
Aniston ANCTL-MP40G1 Multimedia Player is a next-generation intelligent LED display controller designed for professional digital signage, video wall and smart city applications. The player integrates content playback, display sending and remote cloud management into a compact, high-performance device.
- Powerful Playback & Processing: Supports up to 1.3 million pixels LED loading capacity with maximum output resolution up to 4096 × 4096 pixels and hardware decoding of H.264 / H.265 4K@60Hz video.
- Smart Remote Monitoring & Diagnostics: Real-time device health monitoring with alerts for connectivity, temperature, storage and playback status, enabling proactive maintenance and reduced downtime.
- Multi-Screen Synchronization: Supports NTP & GPS time synchronization, ideal for large video walls and distributed signage applications.
- Flexible Network Connectivity: Gigabit LAN connectivity, built-in Wi-Fi AP & Wi-Fi STA modes and optional 4G module support for remote deployment with cloud-based publishing & monitoring.
- Integrated Multimedia Control: USB content playback & firmware upgrades, HDMI input with loop output support and sensor integration for auto brightness control.
- Reliable Commercial-Grade Design: Android-based embedded system with intelligent remote management designed for 24×7 commercial operation.
- Synchronous & Asynchronous Operation: Dual working modes for live input or stored media playback with automatic full-screen scaling in synchronous mode.
Built on a powerful quad-core ARM processor with advanced video decoding, the multimedia player enables seamless synchronous and asynchronous playback, remote content publishing, multi-screen synchronization and intelligent monitoring.
With built-in Wi-Fi, Gigabit Ethernet and optional 4G connectivity, the ANCTL-MP40G1 delivers reliable, flexible and scalable deployment for modern commercial LED display networks.
Product Features
- Powerful Playback & Processing - Supports up to 1.3 million pixels LED loading capacity. Maximum output resolution up to 4096 × 4096 pixels. Hardware decoding of H.264 / H.265 4K@60Hz video. Smooth multi-media playback (4K / Full HD / HD).
- Smart Remote Monitoring & Diagnostics - Real-time device health monitoring with alerts for connectivity, temperature, storage and playback status, enabling proactive maintenance and reduced downtime across large LED display networks.
- Multi-Screen Synchronization - Supports NTP & GPS time synchronization. Perfect for large video walls and distributed signage.
- Flexible Network Connectivity - Gigabit LAN connectivity. Built-in Wi-Fi AP & Wi-Fi STA modes. Optional 4G module support for remote deployment. Remote cloud-based publishing & monitoring.
- Integrated Multimedia Control - USB content playback & firmware upgrades. HDMI input with loop output support. Sensor integration for auto brightness control.
- Reliable Commercial-Grade Design - Android-based embedded system. Intelligent remote management. Designed for 24×7 commercial operation.
- Synchronous & Asynchronous Operation - Dual working modes for live input or stored media playback. Automatic full-screen scaling in synchronous mode. Ideal for live events, advertising and corporate displays.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Multimedia Player |
| Model Number | ANCTL-MP40G1 |
| Max Loading Capacity | 1,300,000 pixels |
| Max Width | 4096 pixels |
| Max Height | 4096 pixels |
| Video Decoding | H.264 / H.265 4K@60Hz |
| Playback Capability | 2x4K / 6x1080p / 10x720p videos |
| Processor | Quad-core ARM processor |
| RAM | 1 GB |
| Operating System | Embedded Android |
| HDMI Input | 1 x HDMI 1.4 |
| HDMI Output Loop | 1 x HDMI 1.4 |
| Audio Output | Stereo audio out |
| USB Ports | 1 x USB 3.0, 1 x USB Type-B |
| Ethernet | Gigabit Ethernet |
| Wi-Fi | AP / STA modes |
| Internal Storage | 16 GB |
| 4G Support | Optional external module |
| Sensor Ports | 2 x Brightness / Temp / Humidity |
| Ethernet Ports | 2 x Gigabit LED outputs + 1 x LAN |
| Control | Cloud / Web / Mobile / PC |
| Input Voltage | DC 12V / 2A |
| Power Consumption | 18W |
| Operating Temperature | -20° to +60° |
| Storage Temperature | -40° to +80° |
| Operating Humidity | 0 - 80% RH (Non-condensing) |
| IP Rating | IP20 |
| Dimensions | 238.8 x 140.5 x 32 mm |
| Weight | 430 g |
| Warranty | 3 years (optional extension to 5 years) |
Mechanical Drawing
Resources & Manuals
Software & Downloads
Coming Soon
