StrixLink USB-100
USB 3.2 Gen 1 (5Gbps) Extender Set
StrixLink USB-100 is a professional USB 3.2 Gen 1 extender pair engineered for stable, low-latency extension of SuperSpeed USB up to 100 m over a single CAT6a cable. It’s backward-compatible with USB 2.0/1.1 and integrates multi-port USB-C/USB-A, RS-232 pass-through, FSYNC GPIO, and bi-directional 24 V PoC—ideal for conferencing, education, control rooms, and industrial camera workflows.
- 100 m SuperSpeed USB 5Gbps: Extends USB 3.2 Gen 1 up to 100 m on one CAT6a run with reliable, low-latency performance.
- Multi-port TX/RX design: TX: 1× USB-C Host, 1× USB-C Dev, 2× USB-A; RX: 2× USB-C Dev, 2× USB-A (total 4× USB-C & 4× USB-A) for maximum device flexibility.
- Pro integration & power: RS-232 pass-through and FSYNC GPIO for camera sync/control, plus 24 V bi-directional PoC so either end can power the pair.
Built with a durable metal enclosure and plug-and-play operation (no drivers), StrixLink USB-100 is ready for 24/7 deployments across boardrooms, classrooms, training centers, production and broadcast setups.
Product Features
- Extends USB 3.2 Gen 1 (SuperSpeed 5Gbps) up to 100 m over a single CAT6a cable.
- Stable, low-latency operation; plug-and-play—no drivers or software required.
- Backward-compatible with USB 2.0 and USB 1.1 devices.
- TX/RX provide a total of 4× USB-C and 4× USB-A device ports for versatile connectivity.
- 24 V PoC (bi-directional): power either TX or RX to power both units.
- RS-232 pass-through (3-pin Phoenix) for third-party control integration.
- FSYNC GPIO (0–5 V) for industrial camera synchronization and automation.
- Supports Isochronous and Bulk transfer modes for real-time AV peripherals.
- Service/Firmware via USB-C service port.
- Robust metal chassis with mounting ears for rack, wall, or under-table installs.
- Operating Temperature: 0°C to 40°C; Storage: −20°C to +60°C.
- Compliance: CE, RoHS; Safety/EMC per IEC-61000.
- Package includes: TX, RX, 24 V adapter, mounting ears, Phoenix connectors, user manual.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | StrixLink USB-100 |
| Product Type | USB 3.2 Gen 1 Extender Set (TX + RX) |
| USB Standard | USB 3.2 Gen 1 (SuperSpeed) |
| Data Transfer Rate | Up to 5 Gbps |
| Backward Compatibility | USB 2.0 / USB 1.1 |
| Supported Transfer Modes | Isochronous / Bulk |
| Transmission Distance | Up to 100 m via CAT6a (F/FTP) |
| USB Ports (TX/RX) | TX: 1× USB-C Host, 1× USB-C Dev, 2× USB-A; RX: 2× USB-C Dev, 2× USB-A |
| Max USB Cable Length | 1.5 m (host/device) |
| RS-232 Pass-through | 3-pin Phoenix (TX/RX/G) |
| FSYNC GPIO | 1-pin Phoenix (0–5 V sync) |
| PoC (Power over Cable) | Bi-directional 24 V PoC (either end powers both units) |
| Enclosure | Metal housing (matte black) |
| Dimensions (each) | 100 mm (W) × 85 mm (D) × 25.5 mm (H) |
| Weight | Approx. TX 265 g / RX 275 g / ~540 g combined |
| Operating Humidity | 20%–80% RH (non-condensing) |
| Storage Humidity | 10%–90% RH (non-condensing) |
| Certifications | CE, RoHS; IEC-61000 (Safety/EMC) |
| Warranty | 3 Years (standard), optional up to 5 Years |
Product Dimension
Resources & Manuals
Software & Downloads
Coming Soon
StrixLink USB-100 – Long-Distance USB 3.2 Gen 1 Extension for Pro AV
The StrixLink USB-100 extends SuperSpeed USB up to
100 m on CAT6a with rock-solid 5Gbps performance. It’s purpose-built
for PTZ cameras, interactive displays, audio peripherals and storage,
adding RS-232, FSYNC GPIO and 24 V PoC for seamless integration.
With plug-and-play setup and a robust metal enclosure, USB-100 is ideal
for classrooms, conference rooms, training centers and broadcast/control
spaces—delivering dependable connectivity without complexity.
Main Features
SuperSpeed USB 5Gbps to 100 m
Extend USB 3.2 Gen 1 up to 100 m over a single CAT6a cable with stable, low-latency performance for mission-critical devices.
Multi-Port, PoC & Control
4× USB-C and 4× USB-A across TX/RX, RS-232 pass-through, FSYNC GPIO, and bi-directional 24 V PoC for streamlined integration and power.
Plug-and-Play, Industrial Design
No drivers or software required. Rugged metal enclosure with mounting ears for rack, wall or under-table installs.
Long-Distance USB for Conferencing & Control
The StrixLink USB-100 carries SuperSpeed USB, RS-232 and FSYNC
over one CAT6a up to 100 m. Ideal for PTZ cameras, interactive displays
and audio peripherals in classrooms, boardrooms and control spaces.
With 24 V PoC and a metal enclosure, it delivers reliable, cable-light
installations and 24/7 performance.
Flexible Ports & Pro-Grade Reliability
TX/RX provide a total of eight USB ports (4× USB-C, 4× USB-A) for devices
such as webcams, microphones, drives and controllers—no drivers required.
Optimized for Isochronous and Bulk transfers, the system ensures smooth
real-time audio/video and dependable device connectivity.
Smart Connectivity with StrixLink USB-100
Elevate system flexibility with the
StrixLink USB-100. Purpose-built for professional and
hybrid environments, it extends USB 3.2 Gen 1 up to 100 m on CAT6a with
bi-directional 24 V PoC, RS-232 and
FSYNC GPIO—and remains compatible with USB 2.0/1.1 devices.
Deployed in boardrooms, classrooms, control centers and signage networks,
USB-100 integrates cleanly without added complexity.
