LumiHolo Pro10 (LHP-101)
10.1″ Compact Transparent Holographic LCD
The LumiHolo Pro10 is a state-of-the-art 10.1-inch transparent LCD engineered for immersive holographic visuals in compact spaces. With ≥75% transparency, 250 nits brightness, and 178° wide viewing, it blends digital imagery with real objects. An embedded Android 7.1+ player (quad-core A53, 1 GB RAM, 8 GB eMMC) plus 10-point PCAP touch enables responsive interactive experiences.
- High-clarity transparent panel: ≥75% panel transparency with >88% glass transmittance for realistic “floating” visuals.
- 10-point PCAP touch: ±2 mm accuracy, ~15 ms response, unlimited durability—supports finger and stylus.
- Integrated Android signage player: Quad-core A53 with Wi-Fi 802.11 b/g/n, 10/100 Mbps LAN, optional 4G for standalone playback and updates.
Ideal for retail counters, educational displays, and museum exhibits, Pro10 adds HDR10 content support, scratch-resistant tempered overlay, and a metal enclosure rated for long-life 24/7 deployments.
Product Features
- 10.1-inch transparent TFT-LCD with 1200 × 800 native resolution for crisp mixed-reality visuals.
- ≥75% panel transparency and >88% glass transmittance preserve clear visibility of real objects.
- 10-point Projected Capacitive (PCAP) touch, ±2 mm accuracy, ~15 ms response, unlimited click durability.
- Wide 178° viewing (89°/89°/89°/89°) with 250 nits brightness and 1000:1 contrast.
- Embedded Android 7.1+ player (quad-core A53, 1 GB RAM, 8 GB eMMC) for native apps and local media.
- Connectivity: Wi-Fi 802.11 b/g/n, 10/100 Mbps Ethernet (RJ45), optional 4G expansion.
- Rear-panel I/O: HDMI, USB 2.0 & 3.0, microSD (Micro Card Slot), RJ45 LAN, audio jack, Wi-Fi antenna connector.
- Integrated stereo speakers (THD <3% within 500 Hz–10 kHz); HDR10 content support.
- Scratch-resistant tempered overlay with enhanced anti-glare coating.
- Industrial metal enclosure with ≥50,000-hour backlight life for reliable 24/7 operation.
- Certifications: CE, RoHS; Warranty: 3 years (optional 5-year extension).
Technical Specifications
| Parameter | Details |
|---|---|
| Model | LumiHolo Pro10 — LHP-101 |
| Product Type | Transparent Holographic Display |
| Panel Size / Type | 10.1″ diagonal, TFT-LCD transparent panel |
| Display Area | 218 × 137 mm |
| Native Resolution | 1200 × 800 |
| Display Colors | 16.7 million (8-bit) |
| Brightness / Contrast | 250 cd/m² (typ.) / 1000:1 |
| Transparency | ≥75% (panel); glass transmittance >88% |
| Viewing Angle (H/V) | 178° (89°/89°/89°/89°) |
| Response Time | 8 ms (gray-to-gray) |
| Field Frequency | 50/60 Hz auto-detect |
| Backlight Life | ≥50,000 hours |
| HDR Content Support | HDR10 |
| Light / Glass | Enhanced anti-glare; scratch-resistant tempered overlay |
| Speakers | Integrated stereo (THD <3% @ 500 Hz–10 kHz) |
| Touch Technology | Projected Capacitive (PCAP), 10-point |
| Touch Accuracy / Min Size | ±2 mm / 5 mm |
| Touch Resolution / Response | 32767 × 32767 / ~15 ms |
| Input Methods | Finger, touch pen |
| Touch Interface | HID-compliant (USB) |
| Embedded OS | Android 7.1 or above |
| Processor / Memory | Quad-core A53-class / 1 GB DDR3 / 8 GB eMMC |
| Network | Wi-Fi 802.11 b/g/n; 10/100 Mbps Ethernet; optional 4G |
| I/O (rear) | HDMI input, USB Type-A (data/storage), USB Type-B (touch), USB 3.0, microSD, RJ45, audio jack, Wi-Fi antenna |
| OSD Languages | English (multi-language available) |
| Dimensions (W × D × H) | 160 × 25 × 240 mm |
| Net Weight | 2.0 kg |
| Certifications | CE, RoHS |
| Mounting Options | Wall mount / kiosk / custom enclosure |
| Warranty | 3 years (optional extension to 5 years) |
Product Dimension
Resources & Manuals
Software & Downloads
Coming Soon
LumiHolo Pro10 — Compact Mixed-Reality for Counters & Kiosks
LumiHolo Pro10 (LHP-101) brings holographic-style visuals
to desks, shelf-edges, and small plinths. Its transparent LCD and precise
multi-touch place digital context alongside real objects.
The embedded Android player (1 GB/8 GB) with Wi-Fi/LAN and optional 4G,
plus rear I/O (HDMI, USB, microSD, RJ45, audio), streamlines deployment
and daily operation in professional environments.
Main Features
Transparent Optics with High Clarity
≥75% panel transparency with >88% glass transmittance preserves visibility of real objects while adding vivid digital overlays.
10-Point PCAP Interactivity
Accurate ±2 mm touch with ~15 ms response enables smooth gestures and reliable interaction for public-facing installations.
Android Player with Rich I/O
Quad-core A53 platform (1 GB/8 GB) with Wi-Fi/LAN, optional 4G, and rear I/O: HDMI, USB 2.0/3.0, microSD, RJ45, and audio out for flexible workflows.
Compact Mixed-Reality with Integrated Control
LumiHolo Pro10 combines high transparency, wide viewing, and responsive
multi-touch in a small footprint. The integrated Android player supports native
apps and local playback — no external media box required.
With HDMI, USB 2.0/3.0, microSD, RJ45, and audio output on the rear panel,
content updates and field servicing are streamlined.
Built for Professional 24/7 Use
A rugged metal enclosure and ≥50,000-hour backlight life make Pro10 a dependable
choice for counters and kiosks.
Wi-Fi/LAN connectivity and optional 4G ensure flexible deployment, while
250-nit brightness, 1000:1 contrast, and 178° wide viewing maintain legibility.
Smart Connectivity for Small-Format Storytelling
Elevate compact displays with the LumiHolo Pro10.
Transparent optics and precise touch invite natural engagement with objects
behind the glass while digital layers add narrative.
Integrated Android, Wi-Fi/LAN, optional 4G, and rear I/O (HDMI, USB, microSD,
RJ45, audio) simplify deployment across counters, podiums, and kiosks.
