Aurelia WE900
Encoder
The Aurelia WE900 by Aniston is a high-performance centralized AV-over-IP controller designed for mission-critical environments such as government operations, enterprise campuses, and educational institutions. It enables seamless control of distributed AV devices through intuitive GUI-based switching, routing, and automation.
- Unified AV Control Platform: Enables real-time drag-and-drop routing for video, audio, USB, RS-232, IR, and CEC signals with visual feedback. Supports matrix switching, multiview configurations, and 9 video wall groups.
- Secure Dual-LAN Architecture: Incorporates independent Video and Control LAN ports with support for HTTPS, SSH, 802.1X authentication, VLAN tagging, and IGMP snooping for robust, secure network segmentation.
- Dante & AES67 Audio Integration: Offers native Dante audio bridging, S/PDIF/ARC/eARC support, latency control, and compatibility with AES67 standards. Facilitates audio passthrough, de-embedding, and embedded source selection.
- Comprehensive Device & User Management: Manages up to 762 devices, supports role-based user access, GPIO triggering, relay outputs, and firmware upgrades with fail-safe rollback via web interface.
- Resilient, Scalable Deployment: Designed for 24/7 operation with fanless heat dissipation, the WE900 includes watchdog monitoring, system logs, backup/restore features, and dual power inputs.
Product Features
- Centralized AV-over-IP management controller designed for campus-wide, enterprise, and government-grade AV deployments.
- Supports matrix switching, multiview control, and drag-and-drop signal routing via a secure web GUI with real-time visual previews.
- Dual-LAN architecture ensures network segmentation—separating AV traffic (Video LAN) and system control (Control LAN) for enhanced security.
- Supports Dante audio routing, AES67, ARC/eARC, S/PDIF, and analog audio integration for flexible audio system compatibility.
- Real-time configuration and signal management of video, audio, USB, IR, RS-232, and CEC across endpoints.
- Scales to manage up to 762 connected devices and nine simultaneous 9×9 video walls.
- Multi-user access with role-based login and customizable user profiles to maintain access integrity.
- Integration-ready with GPIO, IR input/output, relay control, and advanced EDID management tools.
- Secure access protocols including HTTPS, SSH, and 802.1X authentication for enterprise-grade data protection.
- Built for 24/7 operation with redundant design considerations and robust firmware update pathways.
- Engineered for future scalability and long-term service in critical AV environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Model Name | Aurelia WE900 |
| Device Type | Centralized AV-over-IP Management Controller |
| Video Management | Drag-and-drop matrix switching, multiview, video wall support |
| Supported Video Walls | Up to 9 independent walls |
| Device Capacity | Up to 762 AV endpoints |
| Audio Integration | Dante, ARC, eARC, S/PDIF, analog I/O; AES67 compatibility |
| Signal Routing | USB, IR, RS-232, audio, video, and CEC paths |
| LAN Architecture | Dual-LAN (Video LAN + Control LAN) |
| Security | HTTPS, SSH, 802.1X, IGMP snooping |
| Control Interfaces | Web GUI, API, GPIO, IR, relay outputs |
| Audio Features | Latency control, multichannel passthrough |
| User Access | Role-based login, secure management |
| Compliance | CE, FCC, RoHS, BIS Certified |
Mechanical Drawing
Software & Downloads
Coming Soon
Scalable AV-over-IP Control for Complex Networked Environments
The Aurelia WE900 by Aniston is a robust AV-over-IP management controller built to
orchestrate
large-scale video distribution systems across enterprise, education, and public sector
environments.
It provides seamless configuration and control of hundreds of encoders, decoders, and
transceivers
through an intuitive web-based interface.
Supporting matrix switching, multiview, and video wall layouts, it integrates advanced
protocol
support (RTSP, SRT, HTTP/HTTPS, Onvif), secure dual-LAN architecture, and Dante audio
bridging.
With role-based access control, IR/RS-232/relay integration, and GPIO triggers, the
WE900 enables
highly secure, customizable deployments tailored for command centers, campuses, and
AV-over-IP
installations at scale.
Main Features
Drag-and-Drop AV Routing
The Aurelia WE900 allows intuitive matrix switching, video wall setup, and multiview configuration using a visual web-based interface. Configure and route video, audio, IR, RS-232, and USB with real-time previews.
Dual-LAN Network Segmentation
Isolates AV-over-IP traffic and control commands using dedicated Video LAN and Control LAN ports. Enterprise-grade protection via HTTPS, 802.1X, SSH, and IGMP snooping ensures secure operation.
Dante Audio Bridge & Protocol Flexibility
Supports Dante audio routing, ARC, eARC, S/PDIF, and analog inputs. Compatible with AES67, the WE900 enables precise signal bridging, latency control, and multi-channel audio integration across IP-based AV networks.
Centralized AV-over-IP Controller for Enterprise-Grade Networked AV Management
The Aurelia WE900 by Aniston redefines control in AV-over-IP systems with its robust
centralized management platform. Designed for large-scale deployments, it streamlines configuration,
routing, and monitoring of encoders, decoders, and AV endpoints across dual LANs.
With features like drag-and-drop matrix switching, multiview management, and Dante audio bridging,
it supports secure and scalable AV infrastructures in corporate, government, and education
environments. Its rack-mountable design and standards-compliant protocols ensure seamless
integration and 24/7 operational reliability.
Secure Dual-LAN Architecture & Multi-Protocol AV Control
The Aurelia WE900 features a dual-LAN design that segregates AV and control traffic to
enhance network security and reliability. Supporting protocols like HTTPS, SSH, IGMP
snooping, and 802.1X, it ensures encrypted communication across distributed
installations.
Seamlessly integrating Dante audio, eARC, ARC, and S/PDIF alongside USB, IR, and RS-232 control, it
enables comprehensive routing through a centralized Web GUI. With GPIO and relay output support, the
WE900 adapts effortlessly to complex AV environments requiring real-time automation and control.
Centralized AV-over-IP Management with the Aurelia WE900 Controller
Optimize your AV network with the Aurelia WE900—a powerful AV-over-IP
management controller from ANISTON. Designed for enterprise-grade environments, it centralizes
control of distributed video, audio, and control signals across large-scale infrastructures.
Equipped with dual-LAN segmentation, Dante audio integration,
and flexible I/O including USB, RS-232, IR, and GPIO, the WE900 supports seamless matrix
switching, multiview layouts, and video wall configurations from a unified Web GUI. Ideal for
control centers, campuses, and hybrid AV ecosystems, it delivers secure, reliable, and
scalable AV orchestration.
